TK450 Universial Bridge S460J0 BS5400 HA+20HB Extra Wide Heavy Load Bailey Bridge Long Span

PRODUCT DESCRIPTION

TK 450 Bridge is the large size of ZB200, it is a robust modular bridging system designed to cope with the heavy-duty vehicles used in construction, mining, oil and gas and extractive industries, and is available for both permanent and temporary applications.

TK450 Bridge uses standardized components, or super panel and a selection of decking systems to create a versatile heavy-duty modular steel bridge system with a clear spanning capability of up to 81m. Achievable span lengths, in span increments of 2.25m or 4.5m , vary according to loading but multiple span structures supported on intermediate piers mean that the suitability of the Mabey Universal™ is not restricted by length of crossing.

Its unique combination of pre-engineered modular components, simple pinned / bolted connections, heavy load capability and robust design makes the system ideal for use as a stock bridge system in country.

APPLICATION

• Permanent or semi-permanent bridging
• Long span bridging
• Rural infrastructure project
• Urban traffic project
• Humanitarian aid and disaster relief operation
• Pedestrian bridging
• Services pipelines
• Construction site access
• Replacement of damaged bridge
• Emergency response stock

Features

• Modular
• Rapid-build
• Can be assembled using light plant
• Can be crane built or cantilever launched
• Relocatable
• Transport in standard containers
• Long span capability
• Single and multi-span solutions available
• Robust
• High fatigue capability
• Heavy axle / Wheel load capacity
• Long life with minimal maintenance
• Optional ramps, footwalks, piers, parapets and barriers
• Various deck options available

 Technical Specification
